Kapre: Keras Audio Preprocessors for Real-time GPU Processing

Introduction

Kapre is a powerful Python library that offers Keras Audio Preprocessors, allowing you to compute essential audio features like STFT, ISTFT, Melspectrogram, and more, directly on the GPU in real-time. Designed for Python 3.8+ with type hints, Kapre integrates seamlessly into your deep learning workflow, making audio feature extraction an integral part of your Keras models.

Installation

Kapre can be easily installed using pip:

pip install kapre

Examples

Integrating Kapre into your Keras model is straightforward. Here's a one-shot example demonstrating how to add STFT and other processing layers to a sequential model:

from tensorflow.keras.models import Sequential
from tensorflow.keras.layers import Conv2D, BatchNormalization, ReLU, GlobalAveragePooling2D, Dense, Softmax
from kapre import STFT, Magnitude, MagnitudeToDecibel
from kapre.composed import get_melspectrogram_layer, get_log_frequency_spectrogram_layer

# 6 channels (!), maybe 1-sec audio signal, for an example.
input_shape = (44100, 6)
sr = 44100
model = Sequential()
# A STFT layer
model.add(STFT(n_fft=2048, win_length=2018, hop_length=1024,
               window_name=None, pad_end=False,
               input_data_format='channels_last', output_data_format='channels_last',
               input_shape=input_shape))
model.add(Magnitude())
model.add(MagnitudeToDecibel())  # these three layers can be replaced with get_stft_magnitude_layer()
# Alternatively, you may want to use a melspectrogram layer
# melgram_layer = get_melspectrogram_layer()
# or log-frequency layer
# log_stft_layer = get_log_frequency_spectrogram_layer()

# add more layers as you want
model.add(Conv2D(32, (3, 3), strides=(2, 2)))
model.add(BatchNormalization())
model.add(ReLU())
model.add(GlobalAveragePooling2D())
model.add(Dense(10))
model.add(Softmax())

# Compile the model
model.compile('adam', 'categorical_crossentropy') # if single-label classification

# train it with raw audio sample inputs
# for example, you may have functions that load your data as below.
x = load_x() # e.g., x.shape = (10000, 6, 44100)
y = load_y() # e.g., y.shape = (10000, 10) if it's 10-class classification
# then..
model.fit(x, y)
# Done!

For more examples and detailed usage, refer to the example folder in the GitHub repository.

Why Use Kapre?

Kapre offers significant advantages over traditional audio preprocessing methods:

Versus Pre-computation

• You can optimize DSP parameters directly within your model training.
• Model deployment becomes simpler and more consistent, with fewer external dependencies.
• Your code and model have reduced dependencies.

Versus Your Own Implementation

• Quick and Easy: Integrate complex audio processing with minimal effort.
• Consistency: Ensures consistent handling with 1D/2D TensorFlow batch shapes and is data format agnostic (channels_first and channels_last).
• Less Error Prone: Kapre layers are rigorously tested against established libraries like Librosa, ensuring accuracy in tricky operations like STFT and decibel conversion.
• Extended APIs: Provides enhanced functionalities beyond default tf.signals implementations, such as a perfectly invertible STFT and InverseSTFT pair, and Mel-spectrogram with more options.
• Reproducibility: Available on pip with versioning for reliable use.

Links

• GitHub Repository: https://github.com/keunwoochoi/kapre
• API Documentation: https://kapre.readthedocs.io
• Citation: If you use Kapre in your work, please cite the following paper:

  @inproceedings{choi2017kapre,
    title={Kapre: On-GPU Audio Preprocessing Layers for a Quick Implementation of Deep Neural Network Models with Keras},
    author={Choi, Keunwoo and Joo, Deokjin and Kim, Juho},
    booktitle={Machine Learning for Music Discovery Workshop at 34th International Conference on Machine Learning},
    year={2017},
    organization={ICML}
  }
