Garage Web UI: An Admin Interface for Garage Object Storage

Introduction

Garage Web UI is an intuitive, self-hosted web interface designed to simplify the administration of Garage, a powerful S3-compatible, distributed object storage service. This project provides a user-friendly dashboard for managing your Garage cluster, making complex operations accessible through a graphical interface.

Key features include:

Monitoring Garage health status.
Managing cluster and layout configurations.
Creating, updating, and viewing bucket information.
An integrated objects/bucket browser for easy navigation.
Creating and assigning access keys for secure access.

Built with TypeScript for the frontend and Go for the backend, Garage Web UI offers a robust and responsive experience for managing your object storage infrastructure.

Installation

Garage Web UI can be easily deployed using Docker, Docker Compose, or as a standalone binary.

Using Docker CLI

docker run -p 3909:3909 -v ./garage.toml:/etc/garage.toml:ro --restart unless-stopped --name garage-webui khairul169/garage-webui:latest

Using Docker Compose

If you are already running Garage with Docker Compose, you can integrate the Web UI by adding it to your docker-compose.yml file:

services:
  garage:
    image: dxflrs/garage:v2.0.0
    container_name: garage
    volumes:
      - ./garage.toml:/etc/garage.toml
      - ./meta:/var/lib/garage/meta
      - ./data:/var/lib/garage/data
    restart: unless-stopped
    ports:
      - 3900:3900
      - 3901:3901
      - 3902:3902
      - 3903:3903

  webui:
    image: khairul169/garage-webui:latest
    container_name: garage-webui
    restart: unless-stopped
    volumes:
      - ./garage.toml:/etc/garage.toml:ro
    ports:
      - 3909:3909
    environment:
      API_BASE_URL: "http://garage:3903"
      S3_ENDPOINT_URL: "http://garage:3900"

Without Docker

For a standalone installation, download the latest binary from the release page. For example, for Linux AMD64:

wget -O garage-webui https://github.com/khairul169/garage-webui/releases/download/1.1.0/garage-webui-v1.1.0-linux-amd64
chmod +x garage-webui
sudo cp garage-webui /usr/local/bin

Then, run the program with your garage.toml configuration path:

CONFIG_PATH=./garage.toml garage-webui

You can also set up a systemd service for automatic startup:

sudo nano /etc/systemd/system/garage-webui.service

Add the following content:

[Unit]
Description=Garage Web UI
After=network.target

[Service]
Environment="PORT=3919"
Environment="CONFIG_PATH=/etc/garage.toml"
ExecStart=/usr/local/bin/garage-webui
Restart=always

[Install]
WantedBy=default.target

Reload and start the service:

sudo systemctl daemon-reload
sudo systemctl enable --now garage-webui

Examples

Once your Garage Web UI instance is running, you can access it via your web browser at http://your-ip:3909. For enhanced security, it is recommended to place it behind a reverse proxy with SSL.

To enable authentication for the Web UI, set the AUTH_USER_PASS environment variable in the format username:password_hash. You can generate the password hash using htpasswd:

htpasswd -nbBC 10 "YOUR_USERNAME" "YOUR_PASSWORD"

Then, update your docker-compose.yml or environment variables accordingly:

webui:
  ....
  environment:
    AUTH_USER_PASS: "username:$2y$10$DSTi9o..."

Why Use It

Garage Web UI offers significant advantages for anyone managing a Garage Object Storage instance:

Simplified Management: Provides a visual interface for tasks that would otherwise require command-line operations, making administration more accessible.
Comprehensive Overview: Get a quick glance at your Garage cluster's health, layout, and resource usage.
Efficient Operations: Easily create, modify, and delete buckets, and manage access keys without manual configuration files.
Self-Hosted Control: Maintain full control over your storage and its management interface within your own infrastructure.
Seamless Integration: Designed to work effortlessly with existing Garage deployments, especially those using Docker.
